This is a horizontally mounted, double compartment Photo-Electrochemical Flow H-Cell used to simultaneously investigate thin film photo-anode and photo-cathode. The cell elements are made of PTFE. It well fits aqueous (EPDM/FKM O-Rings) and organic solvent (FFKM O-Rings) electrolyte requirements. The construction is liquid-tight having two separate chambers, each equipped with an electrolyte inlet and outlet. This allows solutions to flow and evacuation of reaction products. Chambers are separated with an ion-exchange membrane (e.g. DuPont’s Nafion® membrane), so the electrochemical products appearing at photo-anode and cathode do not affect the opposite electrode.

Specification

• nominal exposure area: 1 cm2
• flow chamber volume: 2×1.5 mL
• electrode plug diameter: 6 mm
• recommended substrate size: 25 mm x 25 mm
• maximum substrate thickness: 4 mm
• maximum membrane thickness: 4 mm

Product includes

• 2 x flow chamber
• 2 x sample holder
• 4 X PLUG
• 1 x table tripod
• 1 x set of Nylon screws
