Moisture Analyzers

The MB95?s halogen heating system distributes heat uniformly over the sample and speeds up the drying process ? delivering fast and precise measurements.

Overview

The MB95’s halogen heating system distributes heat uniformly over the sample and speeds up the drying process — delivering fast and precise measurements. Designed for tool-free cleaning, the MB95’s components can be easily removed for quick and easy maintenance. Operating the MB95 is intuitive with the icon-driven menu navigation on the touchscreen display.

Specifications

Model MB95
Capacity 90 g
Readability 0.01%/0.001 g
Repeatability (Std Dev) (g) 0.1% (3 g sample)
0.018% (10 g sample)
Moisture Range 0.01% to 100%
(0.01% to 1000% for regain mode)
Heating Element Halogen
Drying Programs Standard, Fast, Ramp, Step
Temp Range 40° – 200° C
Switch-off Criteria Manual, Timed, Auto (30, 60, 90 seconds)
Adjustment External adjustment mass – 50 g
Power 100 – 120 VAC 5A 50/60 Hz
200 – 240 VAC 2.5A 50/60 Hz
Operating Temperature Range 5° to 40°C
Display Type 4.3’, QVGA, TFT touch screen
Display Results %moisture, %solids, %regain, time, temperature, weight, method name, drying curve and statistics
Pan Size (mm) Ø 90
Interface RS232, USB host, USB device
Adjustable Feet and Level Yes
Dimensions (W x H x D) (mm) 210 x 180 x 350
Net Weight 5.23 kg
Shipping Weight 8.35 kg

Features

Increase Efficiency in your Lab with Fast Heating Halogen Technology. The MB95’s precisely controlled halogen heating dries samples quickly and ensures uniform heating to yield fast, precise and repeatable results of 0.01% readability. Four drying profiles and five switch-off criteria help to perform customized sample tests.
Define your Drying Parameters and Store Up to 20 Methods for Easy Recall MB95 can help you store up to 20 methods and 200 total results, for statistical analysis of measurements.
Effortless Maintenance with the Tool-Free Cleaning Design Designed with effortless maintenance in mind, the MB95 features a removable pan handler and heating chamber components that make cleaning quick and easy—no tools needed.
Touchscreen Icon-Based Menu Navigation Guides Users through Every Step Icon-based menu navigation on the easy to-read touchscreen display makes operating the MB95 intuitive. Perform routine sample testing in three easy steps—no training required.
